Nalift 2.5t electric articulated forklift trucks

all the work of counterbalance forklift and reach truck can be done by only one Nalift narrow aisle articulated forklift. This innovative design brings a lot of convenience to customers, including narrower warehouse access, higher work efficiency, better driving experience and lower operating costs.

  • رقم الصنف.:

    NALIFT25
  • دفع:

    EXW/FOB/CFR/CIF/DDU
  • أصل المنتج:

    China
  • اللون:

    Customized
  • ميناء الشحن:

    Any port in China
  • المهلة:

    30 Days
  • تفاصيل المنتج
product Item: Nalift 2.5t electric articulated forklift trucks


The Nalift versatile articulated forklift trucksprovides the lowest cost of ownership while maximizing space and productivity to benefit every users.

Nalift VNA forklifts are designed to withstand heavy-duty use both inside and outside, it can drive on any floor surface, eliminating double handling, moving pallet from lorry to racks in one step. comparing to reach trucks, Nalift very narrow aisle trucks creats 30% more pallet positions, compairing to counterbance forklifts, it creats 50% morepallet positions so the Nalift VNA articulated forkliftscan save users much time, space and money.


full Nalift articulated forklifts ranges are standard equipped with 80V ac ZAPI dual-core controller which makes it has a lower failure rates and creates lower heat after long time using, 80V ac lifting motor and driving motor and 80V 400ah-600ah lead acid battery or li-ion batterywhich provides stronger power, increases efficiency and greatly reduces maintenance costs.


advanced parts descriptions


finger joystick



fingertip armrest

combines fingertip armrest and electro proportional valve, Nalift VNA forkliftsprovides better driving experience, more flexible and accurate operation. it also provi des a special picking mode, easy for drivers to load/unload pallets in narrow aisles. With better inching performance, it makes the Nalift articulated forkliftsvery suitable for high-intensity work.



forklift valve
proportional valve
Electro-hydraulic proportional valve match with fingertip armrest can adjust the speed of mast lifting/falling, side shift and tilting at will, making it easier and more accurate to pick up/unload goods in narrow aisles.




zapi controller





ZAPI controller

Nalift VNA articulated forkliftranges are standard fitted with 80V full ac ZAPI dual-cor e controller. as the voltage is higher, it produces lower current, lower heating, lower failure rate. Therefore, all electrical components will have a longer service life.






electric motor




lifting m otor (left)

fitted withexternal encoder bearing, easy for maintenance. 80V ac 15kw/h
lifting speed: 0.44/0.5m/s



driving m otor (r ight)
fitted withexternal encoder bearing,e asy for maintenance
80V ac 19.5kw/h
Driving speed: 16km/h
G radeability: 18%/20%



forklift seat



adjustable sus pension seat

ops system
safe belt
high suitability


forklift gear


bearings

The steering motor drives the large gear ringthrough the small gear ring, which is more labor-saving and has longer service.


extremely small gear clearance ensures structural stability and thus reduces failure rates.


10 years warranty for the gear.



cooling fans


cooling fans

allN alift VNA forklifts are equipped with two efficient cooling fans, even in high temperature environment itcan quickly cool down the motor and gear pump.


guiding laser
guiding lasers
When the laser point to pallet center then drivers can steer direction, pushing forks into fork section accurately. it reduces accidents greatly.


configurations

standard parts optional parts
fingertip armrest wireless camera and monitor
Electro-hydraulic proportional valveL ithium ion battery
80VACZAP i controllerDo uble deep forks
80V ac lifting&;driving motor
weighing forks
80V 400AH lead acid battery and customized charger station
height pre-selector
led&; war ning light
cabin
C ooling fans
white tyres
T riplex full free mast
quad mast
integral s ide shift fork positioner
load backrest

black solid tyres

backup mirror
suspension seat with safety belt and ops system

guiding lasers

Specifi cations

model unit NALIFT25
capacityKG 2500
mastl ift heightMM 4300-12400
mast f ree lift heightMM 1365-4686
mast closed heightMM 2265-5665
mast full extended heightMM 5561-13739
overall length(excluding forks) MM 2780
ground clearanceMM50
overhead guard heightMM 2270
chassis width rearMM 1400
chassis width frontMM 980
load centerMM 600
wheelbaseMM 1735
seat heightMM 1220
mast tilt angle(back/fwd) degree 3/1
front chassis rotate angle(left/right) degree 220
ground speed km/h16
lift speed(load/unload) M/S 0.44/0.5
front tyre sizeMM 412x174
rear tyre sizeMM 457x170
grade ability(load/unload) %18 /20
battery voltage/capacity V/AH 80/500
We ight including batteryKG 5150
weight excluding batteryKG 7400
traction motorKW 19.5
lifting motorKW15
min n et working aisle widthMM 1900
transfer aisle widthMM 2700

less cost
narrower aisle
higher productivity


lift up To 12400mm
smart Fingerti p Armre st

80V full ac control system

aisle width as narrow as 1900mm


The full range of the articulating narrow aisle forklift trucks:
NALIFT15 rated capacity 1500KG, lift height 4300mm -7050mm,
NALIFT20 rated capacity 2000KG, lift height 4300mm-10050mm,
NALIFT25 rated capacity 2500KG, lift height 4300mm-12400mm,
NALIFT30 rated capacity 3000KG, lift height 4300mm-12400mm.
